The Fusion 17 is ideal for any application whether it is estuary or coastal fishing or an afternoon family cruise. The deck length allows for enough space for the whole family, yet small enough for easy, hassle-free towing and deploying.
From R 380 620,00
Specifications
Fusion 17
Details |
Specifications |
| Internal Volume | 3.04 cu |
| LOA | 5.69 m |
| Waterline length | 4.740 m |
| Waterline Beam | 1.870 m |
| Chine Beam | 1.850 m |
| BOA | 2.1 m |
| Freeboard (Amidship) | 0.46 m |
| Draft | 0.33 m |
| Deadrise | 13.9 degree |
| Transom | 15 degree |
| Transom Height | 580 mm |
| Electronic trolling motor | 80 pound thrust, 60 inch shaft |
| Min HP and Shaft lengths | Single: 60 HP L |
| Max HP and Shaft lengths | Single 140 HP L, Twin: 2 x 40 HP L |
| Max KW | 115 kw |
| Maximum Speed | 40 knots |
| GRP Construction | Yes |
| Wet deck | Yes |
| CAT C Buoyancy | 106.78% |
| SAMSA CAT R | 7 People |
| SAMSA CAT E | 5 People |
| SAMSA CAT D | 5 People |
| SAMSA CAT C | 4 People |
| Trailer Wheels | 14” |
| LOA on trailer with motor up | 7910 mm |
| LOA on trailer with motor down | 7590 mm |
| HOA overall on trailer | 2150 mm |
| Overall width of trailer | 2215 mm |
| Weight of boat | 540 kg |
| Displacement Weight | 1318.6 kg |
| Weight of trailer | 372.49 kg |
| Boat and trailer weight combined (Dry) | 912.49 kg |
Standard Features
Kevlar keel strip, Swimming platform with adjustable step ladder, 4 x Grab bars on gunnel, 1 x Sampson post & bow roller, 6 x Railblaza starports, Bumper rail, Anchor hatch, Helm Seat with cushions and adjustable back rest, 2 x Forward seat hatches with stainless steel osculati gas struts, 2 x AFT Hatches, 2 x Large scuppers, Optional hull colour gelcoat
Optional extras
Aluminium Single Axle Breakneck Trailer, Bolt On Guide Arms with PVC Tubing, Boat Buckle (Set of 2), Casting Platform, AFT Casting Platform, Forward Seat Cushions x 3, Forward Sun Bed Cushion x 1, AFT Cushion x 2, Ski Bar Single Engine with 2 x additional starports, Ski Bar Twin Engine with 2 x additional starports, Black Powder Coating, Live Bait Water Aeration System, Deck Wash Combo, Built in Cooler Box under forward console seat with drainage onto deck, 4 x Retractable 4 1/2″ Cleats, EVA Decking.
